5018 Telehandler

Capacities

Max. capacity: 5000 kg

Max. lifting height: 17.5m

Max. outreach:9.6m

Weight and dimensions

Overall length to carriage:6.4m

Length to face of forks:7.62 m

Overall width:2.4m

Overall height:2.55 m

Wheelbase:3.15m

Ground clearance:0.38

Overall cab width:0.84 m

Tilt-up angle :12 °

Tilt-down angle :114°

External turning radius(over tyres) :4.1 m

Unladen weight(with fork):13860kg

Forks length/ width/ section:1220 mm x 125 mm / 50 mm

Performances

Lifting:18 seconds

Lowering:14.4 s

Extension :17.9s

Retraction :16.5 s

Crowd :5.1s

Dump :4 s

Engine

Engine brand :Yuchai (Cummins/Perkins)

Engine norm ：National II

Max. fuel sulphur content ：5000 ppm

Engine model ：YCD4J22T-125

Number of cylinders / Capacity of cylinders ：4 - 4400 cm³

I.C. Engine power rating - Power ：122 Hp / 91 kW

Max. torque / Engine rotation ：400 Nm @ 1400 rpm

Drawbar pull (Laden) ：10000daN

Transmission

Transmission type ：Torque converter (optional hydrostatic)

For more detailed configurations, please consult sales staff
